RATTMMOTOR STL-63 110V Pneumatic Punch Press Machine with Controller and Double Button, Small Desktop Punching Press Hand Machine 0.5-0.8Mpa Operation Pressure 200KG
$233.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by kristyjessica.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$233.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by kristyjessica.com
Free 30-day returns Details
Product details
| Management number | 221706338 | Release Date | 2026/05/03 | List Price | $93.20 | Model Number | 221706338 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- ✅【Model Description:】Model: STL63; Cylinder Diameter: 63mm; Cylinder Stroke: 75mm; Cylinder Stroke Adjustable Range: 50mm: If the maximum cylinder stroke is 75mm, reduce by 50mm, the minimum stroke is 25mm. shortening the stroke can reduce the consumption of air supply.
- ✅【Model 63 Parameters】Worktable area: 135*150mm; Closed height: 200mm; Mould shank hole: diameter 16mm; Weight: 16KG; Cylinder specification: 63x75-50; Inlet pipe specification: 8*5MM; Theoretical pressure: gas control/electric control.
- ✅【Use industry】Can be equipped with more than 70L air pump, suitable for small accessories, plastic parts, plaster moulding, copper rivets, press-fit and so on.
- ✅【Controller + double buttons】Equipped with controller function: full-automatic, semi-automatic, manual, counting; cylinder down stay time 99.9 seconds or less adjustable, cylinder return stay time 99.9 or less adjustable, etc. Functions, must be both hands at the same time to press the double button to start the work, high security.
- ✅【Product features】Compressed air as power source, high efficiency and easy to operate, can reduce labour, can be applied to manual operation, automated assembly line integration operation; according to different products or moulds, adjust the height, speed, stroke, pressure size and stamping time.
| Brand Name | RATTMMOTOR |
|---|---|
| Hole Count | 1 |
| Part Number | STL63-C-B |
| Sheet Count | 1 |
| Manufacturer | RATTMMOTOR |
| Material Type | Metal |
| Operation Mode | Automatic, Manual |
| Pin Hole Diameter | 16 Millimeters |
| Included Components | STL-63 110V Pneumatic Punch Press Machine with Controller and Double Button |
